Chapter 12.1

If \(x\) is a node of a min-heap, then we have \(x.key \leq x.left.key\) and \(x.key \leq x.right.key\). If \(x\) is a node of a binary search tree, then we have \(x.left.key \leq x.key \leq x.right.key\). Since we cannot determine the sorted order of the left child and the right child of a node via the min-heap, we cannot print out the keys of an \(n\)-node min-heap in sorted order in \(O(n)\) time.

INORDER-TREE-WALK-ITER(x)
    let S be a new stack
    PUSH(S, x)
    while not EMPTY?(S)
        cur = POP(S)
        while cur != NIL
            PUSH(S, cur)
            cur = cur.left
        if not EMPTY?(S)
            prev = POP(S)
            print prev.key
            PUSH(S, prev.right)

INORDER-TREE-WALK-ITER-NO-STACK(x)
    cur = x
    left_done = FALSE
    while cur != NIL
        if left_done == FALSE
            while cur.left != NIL
                cur = cur.left
            left_done = TRUE
        print cur.key
        if cur.right != NIL
           cur = cur.right
           left_done = FALSE
        else while cur.p != NIL and cur == cur.p.right
                cur = cur.p
            cur = cur.p

Implementation

PREORDER-TREE-WALK(x)
    while x != NIL
        print x.key
        PREORDER-TREE-WALK(x.left)
        PREORDER-TREE-WALK(x.right)

POSTORDER-TREE-WALK(x)
    while x != NIL
        POSTORDER-TREE-WALK(x.left)
        POSTORDER-TREE-WALK(x.right)
        print x.key

Since we could get the ordered list from the binary search tree in \(O(n)\) running time, the comparison-based algorithm for constructing a binary search tree from an arbitrary list of \(n\) elements should take \(T(n)\) time in the worst case that

\begin{align*} &T(n) + O(n) \geq \Omega(n\lg n)\\ \implies &T(n) = \Omega(n\lg n) \end{align*}
